10 Gram Ozonator Price in Pakistan
The 10 Gram Ozonator from Hydrous Water Technology is a commercial ozone-generation system designed for water treatment, oxidation and disinfection applications.
With an ozone production capacity of 10 grams per hour, it is suitable for appropriately designed RO plants, mineral water plants, bottled water plants, commercial water-treatment systems and water storage/contact systems.
Ozone output, concentration and actual treatment capacity depend on the feed gas, water quality, ozone demand and system design.
10 Gram Ozonator for Water Treatment
The 10 Gram Ozonator is designed for commercial and industrial water-treatment applications where ozone is required for oxidation and disinfection.
Ozone (O₃) is a strong oxidizing agent that can be transferred into water through an appropriate injector, diffuser or ozone-contact system. It is commonly used in water-treatment processes to help control microorganisms, odors and certain oxidizable contaminants.
A properly designed ozone system can be integrated with RO and filtration plants as part of a complete water-treatment process.
10g/hour Ozone Production
This model is rated for 10 grams of ozone production per hour. Actual ozone concentration and treatment performance depend on the feed-gas arrangement and operating conditions. Some 10 g/hour systems are designed for oxygen feed and provide adjustable ozone concentration and gas flow.
For this reason, the 10 g/hour output should not be interpreted as a fixed water-flow capacity. Water flow must be determined from the required ozone dose, water quality and contact time.
How Does a 10 Gram Ozonator Work?
The ozone generator uses an electrical discharge process to convert oxygen-containing feed gas into ozone.
The generated ozone can then be transferred into water through a suitable ozone injector, diffuser or mixing arrangement.
A typical treatment arrangement is:
Ozonator → Ozone Tubing → Injector/Diffuser → Contact Tank → Treated Water
For larger water-treatment systems, a properly designed ozone-contact and off-gas arrangement may also be required.
Technical Specifications
| Specification | Details |
|---|---|
| Product | 10 Gram Ozonator |
| Ozone Output | 10 g/hour |
| Ozone Type | O₃ |
| Application | Water oxidation & disinfection |
| Suitable Systems | RO, mineral water, bottled water & commercial water treatment |
| Ozone Generation | Electrical discharge / corona discharge* |
| Feed Gas | Air or oxygen depending on configuration* |
| Power Supply | 220V AC / 50Hz* |
| Cooling | Air cooled* |
| Ozone Concentration | Depends on feed gas and configuration |
| Ozone Gas Flow | Depends on configuration |
| Installation | Wall mounted / tabletop depending on model |
| Enclosure | Stainless steel |
| Control | Analog / timer-controlled depending on supplied configuration |
*Confirm the exact specification of the supplied Hydrous unit before publishing these values as fixed product specifications.
A 10 g/hour ozone system can have substantially different power consumption, ozone concentration, gas flow and dimensions depending on its feed-gas and generator configuration, so these should not be generalized across every 10 g/hour machine.
Key Features
- 10 grams/hour ozone output
- Commercial water-treatment application
- Suitable for RO plants
- Suitable for mineral water plants
- Suitable for bottled water plants
- Suitable for commercial water treatment
- Stainless-steel enclosure
- Compact equipment design
- Ozone-based oxidation and disinfection
- Suitable for integration with ozone contact tanks
- Adjustable operation depending on configuration
- Suitable for controlled ozone treatment systems
Applications
RO Plant Water Treatment
The 10 Gram Ozonator can be integrated into appropriately designed commercial or industrial RO systems where ozone treatment is required.
Mineral Water Plants
Suitable for mineral-water production systems requiring an ozone-based disinfection or oxidation stage.
Bottled Water Plants
Can be integrated into bottled-water production systems as part of the water-treatment and hygiene process.
Commercial Water Treatment
Suitable for commercial water-treatment installations requiring ozone oxidation or disinfection.
Drinking Water Treatment
Ozone can be used as part of a properly engineered drinking-water treatment process.
Water Storage & Contact Tanks
The generated ozone can be introduced into a suitably designed contact tank to provide ozone-water contact time.
Industrial Water Treatment
Depending on water quality and ozone demand, ozone can be incorporated into selected industrial water-treatment processes.
Benefits of Ozone Treatment
Effective Oxidation
Ozone is a powerful oxidizing agent and can react with various oxidizable substances in water.
Water Disinfection
Ozone can be used as a disinfection stage in appropriately designed water-treatment systems.
Odor & Taste Control
Ozone treatment can help control certain unwanted odors and tastes associated with water quality.
Non-Chlorine Treatment
Ozone provides an alternative oxidation/disinfection approach to conventional chlorine dosing in suitable applications.
Automated Treatment
The ozonator can be incorporated into an automated water-treatment system with appropriate controls.
Important Ozone System Sizing Information
The 10 Gram Ozonator is not automatically rated for a particular number of liters per hour.
The required ozone dosage depends on:
- Raw-water quality
- Organic load
- Microbiological load
- Iron and manganese levels
- Water flow rate
- Ozone concentration
- Gas flow
- Ozone transfer efficiency
- Contact time
- Required treatment result
For example, published 10 g/hour water-treatment systems can specify different water-flow capacities depending on ozone concentration and system configuration.
Therefore, customers should provide their water flow and water analysis when selecting a complete ozone-treatment system.
Installation
The ozonator should be installed in a clean, dry and adequately ventilated location.
A typical installation consists of:
10g Ozonator
↓
Ozone-Compatible Tubing
↓
Venturi Injector / Ozone Diffuser
↓
Ozone Contact Tank
↓
Treated Water
For larger installations, an appropriately designed ozone off-gas treatment arrangement may also be required.
Safety Precautions
Ozone is a strong oxidizing gas and must be handled carefully.
- Do not inhale concentrated ozone gas.
- Install the equipment in a properly ventilated area.
- Use ozone-compatible tubing, fittings and seals.
- Check all ozone connections for leakage.
- Keep electrical connections protected from water.
- Do not operate the unit in an enclosed unventilated space.
- Use an appropriate contact tank for water treatment.
- Follow the operating instructions supplied with the equipment.
- Installation and commissioning should be performed by a qualified technician.
What’s Included
Depending on the selected configuration, the supply may include:
- 1 × 10 Gram Ozonator
- Ozone outlet connection
- Power connection
- Basic ozone tubing/accessories according to configuration
- Operating guidance
Ozone injector, contact tank, pump, diffuser and additional installation components should be confirmed separately according to the project requirement.
10 Gram Ozonator Price in Pakistan
The 10 Gram Ozonator price in Pakistan depends on the actual machine configuration, ozone concentration, feed-gas arrangement, controls, enclosure, accessories and availability.
Frequently Asked Questions
What is a 10 Gram Ozonator?
A 10 Gram Ozonator is an ozone-generation system designed to produce approximately 10 grams of ozone per hour for suitable oxidation and water-disinfection applications.
What is a 10 Gram Ozonator used for?
It can be used for appropriately designed RO plants, mineral water plants, bottled water plants, commercial water-treatment systems and other applications requiring ozone treatment.
Can a 10 Gram Ozonator be used with an RO plant?
Yes. It can be integrated into a properly engineered RO water-treatment system according to the required ozone dosage and treatment process.
How much water can a 10 Gram Ozonator treat?
There is no universal water-flow capacity for every 10 g/hour ozonator. Required ozone dose, ozone concentration, water quality and contact time must be considered when designing the system.
Does a 10 Gram Ozonator remove bacteria?
Ozone is used as an oxidation and disinfection agent. Actual microbial reduction depends on ozone concentration, contact time, water quality and the overall treatment-system design.
Is the 10 Gram Ozonator suitable for bottled water plants?
Yes, it can be used in appropriately designed bottled-water treatment systems where ozone treatment is required.
Can Hydrous supply a complete ozone treatment system?
Yes. Hydrous Water Technology can provide ozone-treatment equipment and assist with the appropriate system arrangement according to the customer’s water-treatment requirements.
Related products
-
1665 FRP Vessel Price in Pakistan
